Infineon Technologies EZ-PD™ PAG2-PD Controlador de fuente de alimentación

Written by: Newton C. Braga
Category: Nuevos Componentes , Industria y Noticias


Los controladores de suministro de energía EZ-PD™ PAG2-PD de Infineon Technologies (CYPAS2174) son controladores secundarios integrados que admiten el modo de rango de potencia extendido (EPR) de suministro de energía USB. El EZ-PD PAG2-PD apunta a adaptadores de corriente USB-C™. El CYPAS2174 encaja bien en diseños flyback AC-DC de alta eficiencia con suministro de energía USB, Qualcomm Quick Charge y otros protocolos de carga estándar. Los dispositivos ofrecen una importante ventaja de BOM al integrar todas las resistencias de terminación de puerta tipo C, reguladores tolerantes de 34 V, Vconn, un controlador de puerta NFET VBUS de alto voltaje, protecciones contra fallas de VBUS, protección contra cortocircuitos de VBUS a CC y un circuito de retroalimentación integrado para regulación de voltaje (VBUS).

Clique aquí para ver las hojas de datos
